12-6 Standard Event Reports and SER Date Code 990215
SEL-351P Manual Técnico
Sx Display x samples per cycle (4 or 16); defaults to 4 if not listed.
Ly Display y cycles of data (1 - LER). Defaults to LER value if not
listed. Unfiltered reports (R parameter) display an extra cycle
of data.
L Display 16 samples per cycle; same as the S16 parameter.
R Specify the unfiltered (raw) event report. Defaults to 16
samples per cycle unless overridden with the Sx parameter.
A Specify that only the analog section of the event is displayed
(current, voltage, frequency, contact outputs, optoisolated
inputs).
D Specify that only the digital section (Protection and Control
Elements) of the event is displayed.
M Display only the communication/Mirrored Bit portion of the
event report.
C Display the report in Compressed ASCII format for use by the
SEL-5601 Analytic Assistant.
Below are example EVE commands.
Serial Port
Command
Description
EVE Display the most recent event report at 1/4-cycle resolution.
EVE 2 Display the second event report at 1/4-cycle resolution.
EVE S16 L10 Display 10 cycles of the most recent report at 1/16-cycle resolution.
EVE C 2 Display the second report in Compressed ASCII format at 1/4-cycle
resolution.
EVE L Display the most recent report at 1/16-cycle resolution.
EVE R Display the most recent report at 1/16-cycle resolution; analog and digital
data are unfiltered (raw).
EVE 2 D L10 Display 10 cycles of the protection and control elements section of the second
event report at 1/4-cycle resolution.
EVE 2 A R S4 Display the unfiltered analog section of the second event report at 1/4-cycle
resolution.
If an event report is requested that does not exist, the control responds:
“Invalid Event”
