Date Code 990215 Standard Event Reports and SER 12-9
SEL-351P Manual Técnico
Table SECTION 12: .3: Output, Input, Protection, and
Control Element Event Report Columns
Column
Heading
Corresponding Elements
(Relay Word Bits)
Symbol
Definition
All columns
.
Element/input/output not picked
up or not asserted, unless
otherwise stated.
Analog Section of Event Report
Out 12 OUT101, OUT102 1 Output contact OUT101 asserted.
2 Output contact OUT102 asserted.
b Both OUT101 and OUT102
asserted.
Out 34 OUT103, OUT104 3 Output contact OUT103 asserted.
4 Output contact OUT104 asserted.
b Both OUT103 and OUT104
asserted.
Out 56 OUT105, OUT106 5 Output contact OUT105 asserted.
6 Output contact OUT106 asserted.
b Both OUT105 and OUT106
asserted.
Out 7A OUT107, ALARM 7 Output contact OUT107 asserted.
A Output contact ALARM asserted.
b Both OUT107 and ALARM
asserted.
Out TC WBTR, WBCL
(see Figure 7.29)
T Trip output contact (WBTR)
asserted.
C Close output contact (WBCL)
asserted.
b Both WBTR and WBCL asserted.
Out Br WBBRK (see Figure 7.29) * Break output contact asserted.
In 12 IN101, IN102 1 Optoisolated input IN101 asserted.
2 Optoisolated input IN102 asserted.
b Both IN101 and IN102 asserted.
In 34 IN103, IN104 3 Optoisolated input IN103 asserted.
4 Optoisolated input IN104 asserted.
b Both IN103 and IN104 asserted.
In 56 IN105, IN106 5 Optoisolated input IN105 asserted.
6 Optoisolated input IN106 asserted.
b Both IN105 and IN106 asserted.
