Date Code 990215 Standard Event Reports and SER 12-17
SEL-351P Manual Técnico
Column
Heading
Corresponding Elements
(Relay Word Bits)
Symbol
Definition
Rem 12 RB1, RB2 1 Remote bit RB1 asserted.
2 Remote bit RB2 asserted.
b Both RB1 and RB2 asserted.
Rem 34 RB3, RB4 3 Remote bit RB3 asserted.
4 Remote bit RB4 asserted.
b Both RB3 and RB4 asserted.
Rem 56 RB5, RB6 5 Remote bit RB5 asserted.
6 Remote bit RB6 asserted.
b Both RB5 and RB6 asserted.
Rem 78 RB7, RB8 7 Remote bit RB7 asserted.
8 Remote bit RB8 asserted.
b Both RB7 and RB8 asserted.
Rem OC OC, CC o OPE (Open) command executed.
c CLO (Close) command executed.
Ltch 12 LT1, LT2 1 Latch bit LT1 asserted.
2 Latch bit LT2 asserted.
b Both LT1 and LT2 asserted.
Ltch 34 LT3, LT4 3 Latch bit LT3 asserted.
4 Latch bit LT4 asserted.
b Both LT3 and LT4 asserted.
Ltch 56 LT5, LT6 5 Latch bit LT5 asserted.
6 Latch bit LT6 asserted.
b Both LT5 and LT6 asserted.
Ltch 78 LT7, LT8 7 Latch bit LT7 asserted.
8 Latch bit LT8 asserted.
b Both LT7 and LT8 asserted.
To Next Page
