Date Code 990430 Configuration, Fast Meter, and Fast Operate Commands D-11
SEL-351P Manual Técnico
"RAW52B","RAW52A","WB52A","WBBRK","WBCL","WBTR","CLCAP","TRCAP","yyyy"
"*","*","*","*","*","*","*","*","yyyy"
"*","*","*","*","*","*","*","*","yyyy"
"*","*","*","*","*","*","*","*","yyyy"
<ETX>
where <STX> is the STX character (02).
<ETX> is the ETX character (03).
the last field in each line (yyyy) is the 4-byte ASCII hex representation of the checksum
for the line.
"*" indicates an unused bit location.
BNA Message
In response to the BNA command, the relay sends names of the bits transmitted in the Status
Byte in the A5D1 message. The first name is the MSB, the last name is the LSB. The BNA
message is:
<STX>"*","*","*","STSET","*","*","*","*","yyyy"<ETX>
where: "yyyy" is the 4-byte ASCII representation of the checksum.
"*" indicates an unused bit location.
The BNA command is available from Access Level 1 and higher.
