G-12 Setting SEL OGIC
®
Control Equation s Date Code 990430
SEL-351P Manual Técnico
Relay Elements and Logic
(corresponding SEL
OGIC Control
Equations listed in parentheses) Resultant Relay Word Bits
Reference
Instruction
Manual
Section
Voltage Elements 27A1, 27B1, 27C1, 27A2, 27B2,
27C2, 59A1, 59B1, 59C1, 59A2,
59B2, 59C2, 27AB, 27BC, 27CA,
59AB, 59BC, 59CA, 59N1, 59N2,
59Q, 59V1, 27S, 59S1, 59S2, 59VP,
59VS, 3P27, 3P59, 27B81, 27AB1,
27BC1, 27CA1, 27AB2, 27BC2,
27CA2, 59AB1, 59BC1, 59CA1,
59AB2, 59BC2, 59CA2, 59Q1,
59Q2
Section 3
Frequency Elements 81D1, 81D2, 81D3, 81D4, 81D5,
81D6, 81D1T, 81D2T, 81D3T,
81D4T, 81D5T, 81D6T
Section 3
Synchronism Check Elements
(BSYNCH)
SF, 25A1, 25A2 Section 3
Directional Elements (E32IV) 32QE, 32QGE, 32VE, 32IE, F32P,
R32P, F32Q, R32Q, F32QG,
R32QG, F32V, R32V, F32I, R32I,
32PF, 32PR, 32QF, 32QR, 32GF,
32GR
Section 4
Instantaneous/Definite-Time
Overcurrent Elements
(67P1TC - 67P4TC, 67N1TC -
67N4TC, 67G1TC - 67G4TC,
67Q1TC - 67Q4TC)
50P1 - 50P6, 50N1 - 50N6, 50G1 -
50G6, 50Q1 - 50Q6, 67P1 - 67P4,
67P1T - 67P4T, 67N1 - 67N4,
67N1T - 67N4T, 67G1 - 67G4,
67Q1T - 67Q4T, 67P2S, 67N2S,
67G2S, 67Q2S
Section 3
Time-Overcurrent Elements
(51P1TC, 51P1TC, 51N1TC, 51N2TC,
51G1TC, 51G2TC, 51QTC)
51P1, 51P2, 51N1, 51N2, 51G1,
51G2, 51Q, 51P1T, 51P2T, 51N1T,
51N2T, 51G1T, 51G2T, 51QT,
51P1R, 51P2R, 51N1R, 51N2R,
51G1R, 51G2R, 51QR
Section 3
Switch-onto-Fault Logic (CLMON) SOTFE Section 5
Communications-Assisted Trip
Schemes
(PT1, LOG1, PT2, LOG2, BT)
PT, PTRX1, PTRX2, PTRX, UBB1,
UBB2, UBB, Z3RB, KEY, EKEY,
ECTT, WFC, Z3XT, DSTRT,
NSTRT, STOP, BTX
Section 5
Trip Logic (TR, TRSOTF, TRCOMM,
DTT, ULTR)
TRIP Section 5
