H-6 Distributed Network Protocol (DNP) V3.00 Date Code 991201
SEL-351P Manual Técnico
Object
Request
(supported)
Response
(may generate)
Obj
*default
Var Description
Func
Codes
(dec)
Qual
Codes
(hex)
Func
Codes
(dec)
Qual
Codes
(hex)
2 1 Binary Input Change without Time 1 6,7,8 129 17,28
2 2* Binary Input Change with Time 1 6,7,8 129,130 17,28
2 3 Binary Input Change with Relative Time 1 6,7,8 129 17,28
10 0 Binary Output - All Variations 1 0,1,6,7,8
10 1 Binary Output
10 2* Binary Output Status 1 0,1,6,7,8 129 0,1
12 0 Control Block - All Variations
12 1 Control Relay Output Block 3,4,5,6 17,28 129
echo of
request
12 2 Pattern Control Block
12 3 Pattern Mask
20 0 Binary Counter - All Variations 1 0,1,6,7,8
20 1 32-Bit Binary Counter
20 2 16-Bit Binary Counter
20 3 32-Bit Delta Counter
20 4 16-Bit Delta Counter
20 5 32-Bit Binary Counter without Flag 1 0,1,6,7,8 129 0,1,7,8
20 6* 16-Bit Binary Counter without Flag 1 0,1,6,7,8 129 0,1,7,8
20 7 32-Bit Delta Counter without Flag
20 8 16-Bit Delta Counter without Flag
21 0 Frozen Counter - All Variations
21 1 32-Bit Frozen Counter
21 2 16-Bit Frozen Counter
21 3 32-Bit Frozen Delta Counter
21 4 16-Bit Frozen Delta Counter
21 5 32-Bit Frozen Counter with Time of Freeze
21 6 16-Bit Frozen Counter with Time of Freeze
21 7 32-Bit Frozen Delta Counter with Time of Freeze
21 8 16-Bit Frozen Delta Counter with Time of Freeze
21 9 32-Bit Frozen Counter without Flag
21 10 16-Bit Frozen Counter without Flag
21 11 32-Bit Frozen Delta Counter without Flag
21 12 16-Bit Frozen Delta Counter without Flag
22 0 Counter Change Event - All Variations 1 6,7,8
22 1 32-Bit Counter Change Event without Time 1 6,7,8 129 17,28
22 2* 16-Bit Counter Change Event without Time 1 6,7,8 129,130 17,28
22 3 32-Bit Delta Counter Change Event without Time
