86 FLOWSIC500 · Operating Instructions · 8025733/1GMJ/V4-2/2022-07 · © SICK Engineering GmbH
Operation
Subject to change without notice
Menu navigation (with device option volume conversion)
Some menu functions are only available when you are logged in with user level “User” or
“Authorized User”:
User level: G Guest (standard) U User (1)
User (2)
User (3)
A1
A2
A3
Authorized user (1)
Authorized user (2)
Authorized user (3)
Access rights: - Hidden View Start/edit
Path G U A2+3 A1 Explanation
Main display: Base volume Vb
FLOWSIC500 menu: User p. 88, §5.2.6.1
Logged in user level
Login
Logout -
FLOWSIC500 menu: Device mode p. 89, §5.2.6.2
Calibration mode
Configuration mode
FLOWSIC500 menu: Device information p. 89, §5.2.6.3
Measuring port
Serial number
Firmware version
Firmware date
Firmware CRC
Metrology CRC
Min. oper. pressure
Max. oper. pressure
Meter factor
Frequency at Qr
Meter factor 2
FLOWSIC500 menu: System settings p. 89, §5.2.6.4
Power supply (1)
Power supply (2)
Date
Time
Timezone
Language
Symbols
LCD test
FLOWSIC500 menu: Conversion p. 91, §5.2.6.5
Conversion: References
Basic pressure
Basic temperature
Ref. conditions
Atmospheric pressure
Conversion: Calculation
Calc. methods
Calc. interval
K-factor (fixed)
Conversion: Gas composition
Density entry type
Reference density
Relative density
CO2 [mol%]
N2 [mol%]
H2 [mol%]
Heating value
Heating value unit
FLOWSIC500 menu: Pressure parameters p. 92, §5.2.6.6
