156 FLOWSIC600 · Technical Information · 8010125 V 4.0 · © SICK AG
Commissioning
Subject to change without notice
5.7.2.2 Configuration of DataLogs
The following parameters can be configured on the Configuration tab of the DataLogs page
(
Figure 76) to best suit the specific application (for more details see
pg. 49, 2.8.3.8 and
following):
● Type of dataset,
● Storage cycle,
● Storage behavior,
● Active flow direction,
● Accounting hour
● Distribution of FRAM capacity.
When the meter is shipped, the DataLogs are preconfigured.
Changes to the parameters "Type of dataset", "Storage behavior" or "Direction"
will erase all entries from the DataLog which is changed.
If configuring these parameters after commissioning, first download and
export all entries according to
2.8.4, to prevent loss of data.
Table 23 Standard DataLogs configuration when meter is shipped *
Configuration
parameter
Hourly log Daily log
Diagnostics
comparison log
Type of Dataset
Diagnostic values Volume counters Diagnostic values
Storage cycle 1 hour 1 day 5 min
Storage behavior Overflow Overflow not applicable
Active flow
direction
Forward Forward Bidirectional
Accounting hour not applicable 0 (midnight) not applicable
Max. number of
entries
Entries for approx. 38
days
Entries for approx. 2
years
20 entries
* Depending on location, the DataLogs for the specific FLOWSIC600 may be
preconfigured to fit the requirements e.g. of API, MID or PTB. These settings
may differ from the defaults described here.
