Settings
Impulse output
Submenu "Impulse output" with the parameters of the
impulse output
Pulse source
Flow Rate a.c.
Variable to be supplied to pulse output
Possible sources see Table 2 (  pg. 32, 2.5.1)-
Depending on the number of available pulse outputs, this
menu can exist once or twice
Pulse factor
3600/m3
Number of pulses to be output per cubic meter
(fmax = 6 kHz)
Impulse update
0.4s
Refresh rate of the frequency output
Impulse mode
Flow+direct.n.o.
The following settings may be chosen (also see  pg. 39,
2.6.3):
- "Flow+direct.n.o."
- "Flow+direct.n.c."
- "Flow+error n.o."
- "Flow+error n.c."
- "Flow +/- n.o."
- "Flow +/- n.c."
- "Flow+state n.o."
- "Flow+state n.c."
(n.o. = normally open: n.c. = normally closed)
- Flow+Dir NC
- Flow+Malf NO
Settings
Digital output
Submenu "Digital output" with the parameters of the digital
output. Parameters can only be changed in "Configuration"
mode
Output D0 0
at Warning n.o.
The following signals can be chosen for all digital outputs
default is "Not active"):
- Error n.o.
- Warning n.o.
- Direction n.o.
- CheckReq n.o.
- Error n.c.
- Warning n.c.
- Direction n.c.
- CheckReq n.c.
Output DO 1
at Warning n.o.
Output DO 2
at Warning n.o.
Output DO 3
at Warning n.o.
Settings
Analog output
Submenu "Analog output" with the parameters of the analog
output
AO source
Flow Rate a.c.
Possible sources for analog output see Table 2 (  pg. 32,
2.5.1)
AO Value at 20mA
1000 m3/h
Volumetric flow rate at maximum current.
Main Menu Submenu Submenu Notes
