FLOWSIC600
Diagnosis
"Diagnosis" menu for the display of diagnostic
information on the meter.
% Error
000 000 000 000
Display of the ratio of incorrect and correct
measurements in percent per path.
Diagnosis
Path x values
Display of further information on path x (path 1 to
4).
VOG 8.9m/s
SOS 343.2m/s
Display of the actual values of flow rate (Velocity
of Gas, VOG) and Speed of Sound (SOS) in path x.
SNR: 25dB 25dB
AGC: 50dB 50dB
Display of the actual signal-to-noise ratio (SNR)
and reception sensitivity (automatic gain control,
AGC) in path x. One value for each direction of
measurement (left: forward, right: reverse).
Diagnosis
System values
Display of further system information.
Flow Rate a.c.
+Qt 1289.3 m
3
/h
Display of the actual volumetric flow rate together
with the direction of flow (positive direction
marked by "+Qv", negative direction marked by -
Qv"
VOG 8.9 m/s
SOS 343.2 m/s
Display of the actual readings of Velocity of Flow
and Speed of Sound.
Act. freq. FO
1245 Hz
Display of the actual frequency at the frequency
output.
Act. current AO
14.54 mA
Display of the actual current at the analog output.
Act.status DOUT
DO2: c DO3: o
Display of the current status of the digital
switching output (c: closed, o: open).
Act. voltage
21.30V
Display of the actual voltage.
FLOWSIC600
Parameters
"Parameters" menu.
Reg.: 3001
0000
Display of all parameters stored in the meter‘s
registers. Navigate through the list of registers
with STEP or DATA.
