Utility programs and protocols
120 MCS100E Operating Instructions 8009504/V YWA7/V3-1/2018-01 © SICK AG
Subject to change without notice
9.1 MCSCONF
The configuration program contains default settings for operation of the MCS100E
software. Usually, the program is supplied in a factory-installed state.
The configuration software is in the same directory as the MCS100E software.
The operation of the configuration program is equivalent to that of the MCS100E
measurement program.
9.1.1 Start of the configuration program
To start the configuration program:
• Select the directory that contains the MCS100E measurement program (e.g.
C:\MCS100E).
• MCSCONF <ENTER>.
• The configuration menu is loaded and displayed.
• Upon confirmation with <ENTER>, the Main Menu is displayed.
9.1.2 Terminating the configuration program
• Terminating of MCSCONF: <ESC> key
• The prompt “Exit Y/N” is displayed and when entering “Y”: “Keep changes Y/N?”.
Upon entering <Y> , the new (changed) configuration will be saved. This entry is
confirmed by <ENTER>.
• If you have made changes in the menu “Directories” during configuration, then the
screen prompt “Create directories? Y/N” will be displayed.
When entering <Y>, the creation of the individual directories is presented on the screen
and confirmed by <ENTER>.
Wrong entries have a disruptive effect or cause nonfunctioning of the mea-
surement program.
Leave changes of the MCSCONF to trained personnel.
