5.7.11.16 Mean square fit data
Specialist: System edit: Mean square fit data
Mean square fit data are used to calculate arithmetic functions, e.g. to scale or linearize
analog inputs. The mean square fit data are read-in by CAL in Specialist: System edit:
Results.
Totally, 10 tables can be calculated.
The columns “value X” and “value CAL” can be edited resp. modified alternatively. After
pressing <ENTER>, the fit point (pair of values X and CAL) is sorted into the table according
to the value of the X value.
“Remark” contains explanatory text.
The arithmetic function according to which the fit points are to be calculated, is entered
into the line “Formula”. “Formula” is identical to the formula that can be entered in
Specialist: System edit: Results. Instead of the formula, also the identification of a
calculation from the tables of Specialist: System edit: Results or Specialist: System edit:
Signal output or Specialist: System edit: Graphic output can be entered.
5.7.11.17 Operator's Notebook
Specialist: System edit: Operator's Notebook
The names listed in the operator’s notebook are only used as a memory aid when entering
programs or when printing etc.
Key assignment:
<F8> Display curves graphically
<Shift–F5> In field X or f(X): Display the calculated formula value.
<ENTER>: Accept displayed value.
