5.7.9 Configuration
Main Menu: Configuration
5.7.9.1 Password for the configuration level
A password has to be entered to edit the menus “Signal output” and “Graphic output”.
The password input is not displayed on the screen.
5.7.9.2 Signal output
Main Menu: Configuration: Signal output
This menu option is used to define the:
• analog signal outputs and the
• Measurement ranges
Max. 32 outputs can be activated.
The menu option is identical to Specialist: System edit: Signal output
Definition of password:
→
p. 121, §9.1.3.1
Settings
Channel Number of the analog output.
Mark () Analog output active ( )/not active.
Name Name of component derived from a list which is based on Specialist: System edit:
Results.
Display list by pressing <ENTER>
Unit Unit of component. Displayed automatically from Specialist: System edit: Results
Measurement
ranges
Switching of the measurement range is programmed here.
Measurement range 2 is the larger measurement range and relevant for the plausibil-
ity check for zero setting- and for calibration, with the drifts etc.
The measurement ranges are automatically switched over (this is also true for the
graphic output). Switching over can be interrogated in the menu Specialist: System
edit: Zero/Calib/Purge programs/other programs
(Variable RHi).
Hysteresis is 5%.
If a component has been defined more than once, then the 1
st
definition is relevant
for the plausibility check.
Relays Number: Number of the relay
The relay “Number” is activated (deactivated) when the measurement range 2 (1) is
active (the relay indicates that the analog output switched to another output range).
0: No relay to be assigned
- Number: Inverted setting
Current 0..20 mA
4..20 mA
