Operation
MCS100E Operating Instructions 8009504/VYWA7/V3-1/2018-01 © SICK AG 55
Subject to change without notice
The cause for a stop in recording of the last data file stored is displayed at the left bottom
corner of the screen. If the cause seems unknown: “Unknown Stop Condition” is displayed.
Start time
The start time of the files stored in archive is indicated here.
Format:
dd.mm.yy hh.mm.ss (day.month.year hour.minute.second)
Time axis
The time scale (x-axis) of the time history is set here.
It is only after quitting the entry field that the display on the screen is updated.
5.7.6 Diagnosis
Main Menu: Diagnosis
This menu option presents the status of the measurement sequence.
A list is displayed from which messages, the active components, temperatures, etc. can be
selected for subsequent display.
While this menu option is active, the <F2> key (display of measured values) is disabled.
The scale for the unit axis (y-axis) is set in the menu Main Menu: Configuration:
Graphic output.
Settings:
Messages Display of current messages
Temperatures
1
1
Additional information and settings --> menu: Specialist: System edit: Temperatures and Pressure
No. Numbering
The following temperatures are default settings
1: O
2
sensor
2: Detector
3: Cell
4: Filter wheels
5: Heating controller 1, 1
st
controller
6: Heating controller 1, 2
nd
controller
7: Heating controller 2, 1
st
controller
8: Heating controller 2, 2
nd
controller
Name Name
Current Current value
Nominal Nominal value
Hysteresis The hysteresis (in °C) defines the switching thresholds of the
temperature controller
Limit Limit monitoring
ERROR 1: Current value > NOMINAL VALUE+limit high
1: Current value < NOMINAL VALUE-limit low
0: Limit not exceeded
ALARM 1: Current value > nominal value+limit high
remains set until RESET is carried out
