Operation
92 MCS100E Operating Instructions 8009504/VYWA7/V3-1/2018-01 © SICK AG
Subject to change without notice
5.7.15.7 Service (TEST)
Specialist: Utilities: Service (TEST)
This program section is only intended for service and test purposes.
5.7.15.7.1 Environment configuration
Specialist: Utilities: Service: Environment configuration
Display Setup
Specialist: Utilities: Service: Environment Configuration : Display Setup
This menu is used to set the display parameters.
Note: The settings are not saved.
TEXT file
Specialist: Utilities: Service: Environment Configuration : TEXT file
This menu is used to select the language of the menu texts. The corresponding files are
identified as:
M1Exxx.TXT whereby xxx e.g. DEU (German), ENG (English).
After selecting the language, go to the main menu to activate the language.
HELP file
Specialist: Utilities: Service: Environment Configuration : HELP file
This menu is used to select the language of the help texts. The corresponding files are
identified as:
M1Exxx.HLP whereby xxx e.g. DEU (German), ENG (English).
Key assignment:
ARROW RIGHT, ARROW LEFT Scroll up/down
ARROW UP, ARROW DOWN Change settings
If you select any other than a .TXT file, then texts can no longer be displayed,
and the measurement program ceases to operate.
 Then, perform a RESET and restart the software (1.bat).
If the file was not entered correctly in the MCSCONF:
 Correct in Directories and Files ( → p. 123, §9.1.3.4) and subsequently start
measurement program anew (1.bat)
The language used when calling in the MCS100E program is derived from the
configuration file MCSCONF, menu: Directories and Files (
→ p. 123, §9.1.3.4). If
you wish another language to be activated upon program start, then you must
enter this there.
The language used when calling in the MCS100E program is derived from the
configuration file MCSCONF, menu: Directories and Files (
→ p. 123, §9.1.3.4).
If you wish another language to be activated upon program start, then you
must enter this there.
