Installation
32 MCS100E Operating Instructions 8009504/VYWA7/V3-1/2018-01 © SICK AG
Subject to change without notice
–In the Specialist menu: Utilities: Service: Environment Configuration: Interfaces
(
→
p. 93):
The “Interfaces” must not be assigned to any COM4. Example:
Figure 12 Settings
– Restart MCS100E.
3.3.2.4 Program start on PC side
1 Install NetOP on PC.
2 Start the NDGUEST.EXE program.
– At the first call-up: Set the parameters for NDGUEST according to the customer
network
Procedure:
→ documentation supplied with the delivery.
– “Quick DIAL”
Specify the telephone number of the MCS100E telephone connection (comma for
“Wait time”)
– The screen content of the MCS100E is shown.
3.3.2.5 Terminating the transfer
1 Switch to the NDGUEST user interface with <ALT-X>.
2 “Remote Control“- “Hang up”
3 “File” - “Exit”
In this block
there may be no COM4
File transfer via modem
→
p. 33, §3.4.2
For more information on NetOP → documentation supplied with the delivery.
