Product description
MCS100E Operating Instructions 8009504/VYWA7/V3-1/2018-01 © SICK AG 19
Subject to change without notice
2.2.6 O
2
sensor (option)
O
2
measurement is carried out by means of a circonium dioxide sensor.
The sample gas flows past the O
2
sensor, the gas exchange inside the sensor takes place
by turbulence. Ambient air which reaches the cell by diffusion is used as reference gas.
2.2.7 Barometric pressure compensation (option)
Barometric pressure compensation for the MCS100E is available as an option.
2.2.8 Interfaces
Fiber optics interfaces
• 2 optical interfaces (fiber optics) for connection of:
– I/O module boxes (containing the digital and analog interfaces) or HC8X heating
controller (
→
p. 26)
–Printer or PC (
→
p. 27)
Electrical interfaces (option)
• 1 serial and 1 parallel interface for connection of:
–PC or MODEM and printer (
→
p. 28, §3.2.3.2)
OR
• 1 serial and 1 Ethernet interface for connection of
–PC and Ethernet (
→
p. 28, §3.2.3.3)
