Operation
MCS100E Operating Instructions 8009504/VYWA7/V3-1/2018-01 © SICK AG 65
Subject to change without notice
5.7.9.6 Zero/Calib/Purge programs
Main Menu: Configuration: Zero/Calib/Purge programs
The programs ZERO, Calibration and Backpurge (of sampling probe) can be adjusted here.
Each second the programs are interrogated cyclically. If the conditions are met, then the
actions are performed.
Active programs, digital conditions, flags etc. can be viewed in Specialist: Utilities: Service:
Display digital status.
As the programs ZERO, calibration and backpurge are factory-programmed, you only need
(and can) enter/modify the times here. The information displayed is based on the entries in
the menu Specialist: System edit: Zero/Calib/Purge programs/other programs.
If the program definitions for ZERO, calibration or backpurge do not exist, the menu cannot
be opened.
Settings
Program Number Number of program.
Program name Name of program.
Active Mark () = program becomes immediately active upon software start.
Cycle Cycle, indicating how often the program will run.
DD:HH:MM: day:hour:minute
Start When starting the measuring sequence the start of this program is
synchronized to this time.
Flag|hh:mm: Flag number OR hour:minute
Duration minutes Duration of time program, thereafter the program becomes inactive again and
has to be started anew.
0: Program is continuously running.
Hold minutes As of the start of the program, the analog output is held for this period in
minutes and then released.
0: Analog output is not held.
Average at minutes Average from this time until final time. (This makes it possible to wait for rise
times.)
Only for the backpurge program:
Interval Total interval containing the pulse time
Length of pulse Duration of the backpurge pulse
Relays The pulse triggers the relay defined here.
At the end of a backpurge program the relay is always set to the rest state. (No
entries possible in this menu.)
