Installation
24 MCS100E Operating Instructions 8009504/VYWA7/V3-1/2018-01 © SICK AG
Subject to change without notice
3.1 Transport
• Protect MCS100E from shock and vibrations.
3.2 Installation and initial commissioning
3.2.1 Preparing the place of installation
Make sure that the bearing capacity of the mounting location is appropriate.
3.2.2 Mechanical installation
MCS100E:
Must be mounted in a vertical position.
Use the existing mounting holes.
Use appropriate mounting material only.
Ensure sufficient heat dissipation, take care that instrument space is minimum 5 cm.
3.2.2.1 Sample gas connections
• Sample gas lines:
– Sample gas inlet: 6 mm fitting with ferrule
– Sample gas outlet: 10 mm fitting with ferrule
WARNING: Risk of injury by a heavy load
The MCS100E weighs approx. 70 kg.
Improper lifting can cause painful and sometimes permanent back injury.
Use proper lifting techniques or auxiliary equipment to lift or move the
MCS100E.
Only qualified personnel trained on the instrument may perform installation
and initial commissioning of the MCS100E.
Please contact SICK Customer Service as required.
WARNING: Hot surface - risk of burns
The surface of the cell insulation is hot.
Allow hot components to cool down.
WARNING: Noxious and irritating sample gas
Depending on the sample gas composition, it is possible that the sample gas
contains noxious or irritating components.
Discharge the gas outlets into the open or to an extractor.
Observe information from the plant operator.
NOTICE: Condensate is formed at the sample gas outlet
When the sample gas cools down, it is possible that condensate is formed at
the sample gas outlet.
Lay the sample gas outlet running downwards so that no condensate is
accumulated.
If necessary, provide for a suitable condensate collecting device and
adequate ventilation.
Protect the measuring gas outlet from frost.
