5.7.7 Messages
Main Menu: Messages
The messages stored in archive from status bar 1 (lower bar) are displayed.
Switching to the messages of status bar 2: <ESC>.
These messages are output automatically to the printer, if the printer is active (Main Menu:
Printer: Print on-line: Protocol Start).
The latest message is stated at the top.
Up to 192 messages are stored.
Settings
Components Result number of the component
Name of component (selectable)
To the right of the
Component
Measurement range (measurement range 2 full-
scale).
Amplification Amplification level of measuring resp. reference
signal
1 = lowest, 19 = highest level.
The subsequent number represents the gain factor
Max. energy is:
Level 1 100% => 232,000 counts
Reference Signal,
Measuring Signal
Counts: The counts increase with the gain factor.
Percent: Value independent of the gain factor.
Example:
Gain fct. 1 and 232,000 counts => 100%
Gain fct. 2 and 232,000 counts => 50%
etc.
Absorbance, no corr. Absorbance, no correction
Absorbance add. corr. Additively and multiplicatively corrected
absorbance
corr.Absorbance: Calculated concentration
Concentration Drift since the first zero setting
Drift total ZERO Related to concentration in % of the measurement
range (displayed at the top).
Drift last ZERO Drift since the last (current) zero setting
Related to concentration in % of the measurement
range (displayed at the top).
Drift total SPAN Drift since the first calibration in % of measurement
range (displayed at the top).
Drift last SPAN Drift since the last calibration in % of measurement
range (displayed at the top).
T90 Time: T90 time in seconds.
Measuring cycle Measurement frequency (for all of the components
together).
