Protocol Start
Main Menu: Printer: Print on-line: Protocol Start
Upon entering the protocol name in this menu option one of the 5 on-line protocols defined
is started. Then all messages of message line 1 as well as the zero and calibration
programs are automatically output to the printer. Only one protocol can be started.
Protocol Stop
Main Menu: Printer: Print on-line: Protocol Stop
The active printer protocol is stopped.
The active printer protocol is displayed and you are prompted whether or not it is to be
terminated.
5.7.8.2 Print Archive (Name)
Main Menu: Printer: Print Archive
This menu option controls the output of the archived measured values to the printer, to a
file or to the screen. For this purpose “protocols” (see next chapter) are defined and the
start and end times are entered, and then the protocol is started (whereby, if necessary,
you will be prompted for the file name).
The name (name) of the archived measurement sequence selected for printing is displayed
in parentheses. This name can be selected in the menu Specialist: System, select for
editing.
5.7.8.3 Start and end
Main Menu: Printer: Print Archive Start and end
Enter start and end time of the protocol to be output, here.
Upon start, the protocol will begin with the 1st time entry found and continue until the last,
respectively until time end. Missing times are printed as empty lines.
5.7.8.4 Protocol Definition
Main Menu: Printer: Print Archive Protocol Definition
This menu option is used to perform the settings for the protocol of the saved data
5 types of protocols can be created and given a name - to ease identification. The entries to
be made correspond to those for the on-line protocol, however, the protocol of archived
data can additionally be output to a file or to the screen.
