Product description
20 MCS100E Operating Instructions 8009504/VYWA7/V3-1/2018-01 © SICK AG
Subject to change without notice
2.3 Data storage
• Storage of measured values ( → p. 44, §5.2).
• Storage of status messages (
→ p. 44, §5.2).
• Storage of results or signal outputs: (
→ p. 86, §5.7.11.14).
2.4 Remote control
In remote control, MCS100E is operated via an external PC.
Screen contents and keyboard commands are transmitted.
• Ethernet (program TINY) (
→ p. 29, §3.3.1).
•Modem (program NetOP) at serial interface (
→ p. 31, §3.3.2).
2.5 Data transmission
2.5.1 Data transmission with MCS100E program
The MCS100E program must be installed on the external PC.
File transfer is carried out via the MCS100E menus (
→ p. 90, §5.7.15.4 and → p. 91,
§5.7.15.5).
Connection of external PC:
• Optical (fiber optics) (
→ p. 27).
• Serial interface (
→ p. 28, §3.2.3.2).
2.5.2 File transfer with modem
• At DOS level (program NetOP) at the serial interface ( → p. 31, §3.3.2).
2.6 Communication protocol
• Communication protocol: Modbus RTU ( → p. 126, §9.3).
• Interface: Serial interface (
→ p. 28, §3.2.3.2).
