Directories
Specialist: Utilities: Service: Environment Configuration : Directories
The structure of the directories of the program can be modified in this menu. The
directories for
•Program
•Graphic
• Temporary files are interrogated one after the other.
Set Date and Time
Specialist: Utilities: Service: Environment Configuration : Set Date and Time
Date and time can be set in this menu.
Interfaces
Specialist: Utilities: Service: Environment Configuration : Interfaces
The hardware default settings of the interfaces are:
• If data are to be sent to an external PC (send data to PC), you must set
- the printer to COM- or LPT1
- the PC to COM3
• If a printer is connected (e.g. for on-line protocol), you must set:
- the printer to COM3 and
- the PC to COM-
• If a modem is connected, you must set :
- the printer to COM or LPT1
- the PC to COM-
Usually pre-assigned:
The structure of the directories used when calling in the MCS100E program is
derived from the configuration file MCSCONF, menu: Directories and Files
(
→ p. 123, §9.1.3.4). If you wish another directory structure to be activated upon
program start, then you must enter this there.
When switching over from summer to winter time (time set back by 1 h), the
(saving) times of the data files may become overlapping.
 To avoid that duplicate entries affect the evaluation of stored files, stop
data recording (Specialist: System edit: Data storage and send to PC) and
erase those files that were created in the preceding hour.
COM1 Detector
COM2 I/O module box (opto-interface)
COM3 Pressure/PC/Modem interface (opto-interface)
LPT1 Internal parallel printer interface
Data bits 8
Stop bits 1
Parity No
