Specifications
MCS100E Operating Instructions 8009504/VYWA7/V3-1/2018-01 © SICK AG 137
Subject to change without notice
Operation and interfaces
User levels 2 user levels (user levels for specialist is password-protected)
Display 7.4" black/white LC display (640*480 pixels)
Input Membrane keyboard (numeric, cursor buttons, function buttons)
Connection of an external keyboard is possible.
Data interfaces 2 serial optical (e.g.: plug connector Hirschmann OVK S 2.2)
Sender LED: 660 nm
Recommended fiber optical cable: Polymer fiber optical cable
980/1000 μm
1 serial electric (optional)
1 parallel electric (optional)
1
1 serial Ethernet (optional)
2
Modem (optional)
Telediagnostic Via the Ethernet/internet connection and/or Modem connection
(RS232) (optional)
1
Not possible in combination with Ethernet interface
2
Not possible in combination with parallel interface
Sample gas (requirements)
Composition Only the sample gas composition designed for the MCS100E
(→ system documentation)
Temperature Application-dependent
Thermostatically controlled to cell temperature
Max. temperature: 200 °C
Operating pressure Outlet open against ambient pressure
Flow rate Recommended: 200 ... 600 l/h
Cleanness Free from dust and condensed components
Utility gas
Instrument air Particle size max. 1 μm,
oil content max. 0.1 ppm,
Dew point -30°C.
Gas connections
Sample gas inlet 6 mm fitting with ferrule (standard)
Sample gas outlet 10 mm fitting with ferrule (standard)
Electrical data
Supply voltage 1~115/230 V ±10 %; 50-60 Hz
Power input Max. 850 VA
