Operation
MCS100E Operating Instructions 8009504/VYWA7/V3-1/2018-01 © SICK AG 71
Subject to change without notice
Calibration factor This factor is used for multiplicative correction of the measured values.
It is calculated automatically upon calibration and can be corrected here, if
required. The calibration factor has an influence on the calculated
concentration.
Left column: Factor for span gas
Internal standard: Factor for internal standard
Extra Offset Extra offset is used for additive correction of systematic drifts in addition to
the offset of the zero measurement.
Extra offset is not taken into account with zero measurement or calibration.
Extra offset is added to the calculated absorbance.
Extra factor The extra factor is used for multiplicative correction of systematic derivations
from the calibration factor. The extra factor has an influence on the calculated
concentration.
The extra factor is not taken into account with zero measurement or
calibration.
Plausibility limits in % of
meas. range for Zero and
Calib. value
The value to be entered (default setting: 6%) defines the tolerance (in % of full
scale) which must not be exceeded by Zero resp. calib. gas sampling (since
the last monitoring).
If the value measured at Zero resp. calib. gas sampling is within the tolerance
as entered here:
The measured value is accepted.
If the value measured at Zero resp. calib. gas sampling exceeds the tolerance
as entered here:
The measured value is accepted, but a message is output to the printer and a
flag (Zero: ER17, Calib ER17: ER18) is set for interrogation in Specialist:
System edit: Zero/Calib/Purge programs/other programs.
0: No plausibility control,
calibration is always performed.
Oppress value If the measured value is less than this value, then display THIS value.
First calibration value Calibration value e.g. after service. Display in concentration.
Used to determine the drift.
Last calibration value Calibration value of last calibration. Display in concentration.
Used to determine the drift.
Actual calibration value Actual calibration value. Display in concentration.
First zero value Zero value e.g. after service. Display in concentration.
Used to determine the drift.
Last zero value Zero value of the last zero. Display in concentration.
Used to determine the drift.
Actual zero value Actual zero value. Display in concentration.
Actual zero value [ABS] Actual zero value. Display in absorbance.
Zero, CALIB all comp. If a zero or calibration program is started with the option “all components”,
then THIS component is set (Yes) or not set (No).
Multiplication by result Multiplication by the indicated result. This is used e.g. for printer correction.
0: No multiplication
Drift in [% measurement
range]
Drift in % of full scale
Drift total CALIB Drift (span gas) since last drift reset (e.g. after service)
Drift last CALIB Drift (span gas) since last drift correction
Factor Equivalent to calibration factor (see above in this Table)
internal Calibration factor for internal adjustment standard
Drift total ZERO Drift (zero gas) since last drift reset (e.g. after service)
Drift last ZERO Drift (zero gas) since last drift correction
