Diagnostics
Display Possible cause Rectification of the error
   Short-circuit on control
inputs A1/2 or
incorrect operation of
A1/2 via EFI
   Short-circuit on control
inputs B1/2 or
incorrect operation of
B1/2 via EFI
   Short-circuit on control
inputs C1/2 or
incorrect operation of
C1/2 via EFI
   Incorrect operation of
D1/2 via EFI
   Incorrect operation of
E1/2 via EFI
 Check the wiring, the digital control inputs or
the wiring to the devices connected via EFI.
 Park/stand-by mode,
the OSSDs are in the
OFF state; the laser is
deactivated.
No error. If the criteria for the park mode or
the stand-by mode are withdrawn, readiness
for operation is re-established.
If the display  does not go off:
 Test the level(s) at the STBY input and at the
control inputs that switch to the monitoring
case with park mode.
 A device connected via
EFI reports a
malfunction.
 Carry out a fault diagnosis of the device
connected with the S300.
Optics cover
calibration active
No error
!   Window for light output
on the optics cover
contaminated
 Clean the window for the light output on the
optics cover.
!  
and
!  
Dazzling of the
contamination
measurement (there
may not be an optics
cover fitted)
 Check whether the S300 is being dazzled by
an external light source, e.g. headlight,
infrared light source, stroboscopic light, sun
etc.
Or:
 Fit the new optics cover (then perform optics
cover calibration).
If you have problems during troubleshooting, contact SICK support. Keep a copy of the
print out of the results of the diagnostics at hand.
