Operating instructions Chapter 12
S300
8010948/YY96/2016-02-17 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 119
Subject to change without notice
Technical specifications
Fig.
80
:
Voltage test after
switching on the OSSDs
Fig.
81
:
Shut
-
down test
Fig.
82
:
Voltage test
Approx. 650
µs
<300
µs
<300
µs
OSSD1
OSSD2
Approx. 650
µs
<300
µs
<300
µs
OSSD1
OSSD2
<300
µs
OSSD1
OSSD2
