Operating instructions Chapter 3
S300
8010948/YY96/2016-02-17 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 21
Subject to change without notice
Product description
Variants
Functions Standard Advanced Professional Expert
Protective field range, radial [m] 2/3 2/3 2/3 2/3
Warning field range, radial
1)
[m] 8 8 8 8
Object resolution [mm] 30/40/50/70/150
2
)
Pairs of output signal switching devices (OSSDs) 1 1 1 1
External device monitoring (EDM) 
3)

3)

3)

3)
Universal I/Os 5 5 5 5
Restart interlock/delay 
3
)

3
)

3
)

3
)
Field sets comprising of one protective field and
two warning fields
1 4 8 16
Programmable monitoring cases in standalone
mode
1 4 32 32
Programmable monitoring cases in an EFI system 32 32 32 32
Static control inputs for monitoring case switching – 2 1 1
Static/dynamic control inputs for monitoring case
switching
– – 2 2
EFI interface (safe SICK device communication)    
Park mode, activation via monitoring case –   
Stand-by, activation via EFI bit or stand-by input    
Configuration memory in the system plug    
Data interface RS<422    
Extended CMS functions (reflector detection, filter
function for the measured values)
– – – 
1)
Warning field range with a remission of 30% (see section 12.1 on page 116).
2)
150 mm resolution can only be configured with the Long Range variant with 3 m scanning range.
3)
Availability depending on the configuration of the universal I/Os (see section 4.8 on page 42).
Tab.
2
:
Functions of the
S300 variants

SICK S300 Specifications

General

Protection Class	IP65
Resolution	30 mm
Interface	RS-422, Ethernet
Power Supply	24 V DC
Operating Temperature	0 °C ... +50 °C
