6 Configuring with STEP 7 or a GSDML File
105
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
Note
You should only use the “Pack” function when the configuration of the IE/AS-i LINK
and all the I/O modules required for the slaves have been completed.
If you want to expand the AS-i line later, enter a value in “Reserved Length” that is
higher than the value displayed in “Assigned Length”.
If you use packing, access to the I/O data of a failed slave does not cause an I/O
access error.
S “Parameters” tab
− “Diagnostic interrupt”
Here, you set the output of various diagnostic interrupts (see also Section
9.2.2):
− Line diagnostics (AS-i powerfail, short to ground, I/O error)
− Configuration diagnostics (extra slave)
− “Address programming”
Here, you can enable or disable automatic or manual address programming
for the underlying AS-i line (see also Section 10.1).
6.2.2 Configuring and Assigning Parameters to the AS-i Slaves
Configuration of the I/O modules for the AS-i slaves
Select the IE/AS-i LINK in HW Config. In the default assignment, the slots of the
IE/AS-i LINK are occupied by placeholder modules for the AS-i slaves. You can
open the properties dialog of a placeholder module (I/O module) by double-clicking
on the relevant row in the configuration table. The properties dialog has the
following three tabs:
S “General” tab
Here, you can change the name of the I/O module and enter a comment.
