5.2.11.2 Packet Type
WBM: “Packet Type” Tab − received packets sorted according to type
The “Packet Type” page displays how many frames of the type unicast, multicast,
and broadcast were received at each port.
Clicking on the “Reset” button resets this counter. If you click on an entry in the
Port column, the “Graphic statistics: Packet Type” page is displayed for the
selected port. You then see a configurable graphical representation of the counter
value.
Parameter Function
Port LAN interface of the IE/AS-i LINK (1 or 2)
Unicast Number of packets to the unicast recipient address
Multicast Number of packets to the multicast recipient address
Broadcast Number of packets to the broadcast recipient address
5.2.11.3 Packet Size
WBM: “Packet Size” Tab − received packets sorted according to length
This page displays how many packets of which size were received.
If you click on an entry, the “Graphic statistics: Packet Size” page is displayed for
the selected port. You then see a configurable graphical representation of the
counter value.
Parameter Function
Port LAN interface of the IE/AS-i LINK (1 or 2)
64 Number of packets with 64 bytes
65−127 Number of packets with 65−127 bytes
128−255 Number of packets with 128−255 bytes
256−511 Number of packets with 256−511 bytes
512−1023 Number of packets with 512−1023 bytes
1024−1518 Number of packets with 1024−1518 bytes
