Siemens SIMATIC NET IE/AS-INTERFACE LINK PN IO User Manual

5 Display / WBM Configuration
76
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
5.2.10.2 FDB (forwarding database)
WBM: “FDB” tab
In the forwarding database “FDB”, the IE/AS-i LINK stores the LAN interface (port)
over which it communicates with a communication partner (MAC address). The
assignment on the IE/AS-i LINK is always dynamic, in other words, the assignment
is deleted after an aging time elapses.
Parameter Function
No. Consecutive number of the table entry.
MAC Address MAC address of the connection partner
Port LAN interface of the IE/AS-i LINK
Status Display of the assignment status (here: always “dynamic”)
5.2.10.3 ARP (Address Resolution Protocol)
WBM: “ARP” tab
The ARP table specifies the assignment between the LAN interface (port) and the
MAC address and the IP address of the last connection partner. The assignment
on the IE/AS-i LINK is always dynamic, in other words, the assignment is deleted
after a certain time elapses.
Parameter Function
No. Consecutive number of the table entry.
MAC Address MAC address of the connection partner
IP address Display of the IP address
Port LAN interface of the IE/AS-i LINK
Type Display of the assignment type (here: always “dynamic”)
