Siemens SIMATIC NET IE/AS-INTERFACE LINK PN IO User Manual

1 Technical Description, Installation Guidelines, Operation
15
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
1.3 Technical Specifications of the Module
The IE/AS-INTERFACE LINK module has the following technical data:
Table 1-1 Technical Specifications
Feature Explanation/Values
AS-i cycle time
(The values apply for the possible full configuration
of an AS-i network on the IE/AS-INTERFACE LINK
in each case)
S 5 ms for 31 slaves with standard addressing
S 10 ms for 62 slaves with A/B addressing
S 10 ms for inputs according to profile S-7.A.7
S 20 ms for outputs according to profile S-7.A.7
S 40 ms for inputs/outputs according to profile
S-
7.A.A
S 20 ms for
fast analog according
to profile
S-7.A.8 and S-7.A.9
S 5 ms for super fast analog according to profile
S-6.0.X
Configuration of the AS-Interface S via keyboard and display
S using STEP 7 or with GSDML file
S using Web Based Management (WBM)
S using the user program (data record interface)
Supported AS-i master profiles M1-M4
Connector for AS-i cable
(single and double master)
over plug-in screw contacts (4-pin);
Permitted current loading from pin 1 to pin 3 or pin
2 to pin 4, maximum 3 A
LAN connectors (2) RJ-45 (10/100 Mbps)
as equal switch ports with full duplex capability
Setting of PROFINET device name and IP
parameters
Setting:
S via keyboard and display
S using STEP 7
S using Web Based Management (WBM)
Power supply from the AS-i cable (line 1)
Current consumption from the AS-i cable
29.5 to 31.6 V DC in compliance with EN 50 295
max. 320 mA at 30 V
Power consumption max. 9.6 W
Cable length max. 100 m
Cable cross-section (AS-i cable) 2 x 1.5 mm
2
(2 x 0.8 mm
2
)
Optional external power supply
(plug-in screw contacts 3-pin)
24 V DC, functional earthing
(18 − 32 V DC)
SELV / LPS or NEC Class 2 is mandatory.
Cable cross-section (power supply) 0.5 to 2.5 mm
2
Ambient conditions
S Operating temperature (vertical installation only) 0 to +60°C
S Transportation and storage temperature
S Operating altitude
−30°C to +70°C
max. 3000 m above sea level
