5 Display / WBM Configuration
58
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
5.2.3 Navigation “System −> Save & Download”
WBM provides the option of saving configuration information in a file on your
computer or TFTP server and to download such data from a file from the computer
or TFTP server to the IE/AS-i LINK.
You can also download new firmware from a file from your computer or a TFTP
server.
5.2.3.1 HTTP (Hypertext Transfer Protocol)
WBM: “HTTP” tab
Parameter Function
Configuration file Here, you enter the name and, if necessary, the directory path of the configuration
file that you want to download to the IE/AS-i LINK in which you want to save the
current configuration information.
As an alternative, you can select the file with the “Browse” button.
Diagnostic buffer With “Save”, you can save the diagnostic buffer on the local computer/network.
