8 Using the Data Record Interface
126
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
Table 8-5 AS-i Slave Calls
Name
Function Index
(deci-
mal)
Data in the send /
receive buffer
Description
Set_Permanent_Parameter Write 3 Parameter value Section 8.2.2.1
Get_Permanent_Parameter Read 4 Parameter value Section 8.2.2.2
Write_Parameter Write 5 Parameter value Section 8.2.2.3
Read_Parameter Read 6 Parameter value Section 8.2.2.4
Set_Permanent_Configuration Write 8 Configuration Section 8.2.2.5
Get_Permanent_Configuration Read 9 Configuration Section 8.2.2.6
Read_Actual_Configuration Read 11 Configuration Section 8.2.2.7
Read_I/O_Configuration Read 33 I/O configuration Section8.2.2.14
Read_ID-Code Read 34 ID code Section 8.2.2.15
Read_Extended_ID-Code_1 Read 24 ID1 code Section 8.2.2.16
Read_Extended_ID−Code_2 Read 35 ID2 code Section 8.2.2.17
Read_Status Read 80 Status of the AS-i
slave (error flags)
Section 8.2.2.18
Get_Write_Parameter_Echo Read 81 Parameter echo
value
Section 8.2.2.19
Write_Analog_Output_Data Write 82 Analog output data of
the AS-i slave
Section 8.2.2.20
Read_Analog_Output_Data Read 83 Analog input data of
the AS-i slave
Section 8.2.2.21
Read_AS-i_Slave_Errorcounters Read 98 Error counters Section 8.2.2.22
Read_and_delete_AS-i_Slave_Errorcoun–
ters
Read 99 Error counters Section 8.2.2.23
Table 8-6 AS-i Slave Calls for Slaves Complying with AS-i Specification V3.0 (CTT1, CTT2)
Name
Function Index
(decim
al)
Data in the send /
receive buffer
Description
Read_Parameter_String Read 27 Parameter string Section 8.2.2.8
Write_Parameter_String Write 28 Parameter string Section 8.2.2.9
Read_Diagnostic_String Read 29 Diagnostic string Section 8.2.2.10
Read_Identification_String Read 30 ID string Section 8.2.2.11
Write_CTT2_String Write 31 CTT2 string Section 8.2.2.12
Read_CTT2_String Read 31 CTT2 string Section 8.2.2.13
