8.2.1.11 Write_Extended_ID−Code_1
Meaning
With this call, the extended ID1 code of an AS-i slave with address “0” can be
written directly over the AS-i cable.
The AS-i master passes on the extended ID1 code to the AS-i slave without any
plausibility check. The ID1 code is stored permanently on the AS-i slave. The ID1
code is stored temporarily on the AS-i master in CDI (RAM).
Structure of the RecordDataWrite service − Index 24
Byte Meaning
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Version_hi = 0x00
1 Version_lo = 0x00
2
0x0 ID1 code
Mode
3 Reserved 0x00
