1 Technical Description, Installation Guidelines, Operation
16
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
Table 1-1 Technical Specifications
Feature Explanation/Values
S Relative humidity Max. 95% at +25°C
Construction
S Type of protection IP 20
S Dimensions (W x H x D) in mm 90 x 132 x 85.5
S Weight approx. 380 g
Receptacle for optional C-PLUG
Full graphics display and 6 control buttons 128 x 64 pixels
1.4 Approvals
Table 1-2 Description of the Approvals
c−UL−us
UL 508
CSA C22.2 No. 142
c−UL−us for hazardous locations UL 1604, UL 2279PT.15
CL. 1, Div. 2 GP.A.B.C.D T4
CL. 1, Zone 2, GP.IIC, T4
CL. 1, Zone 2, AEx nC IIC T4
FM FM 3611
CL. 1, Div. 2 GP.A.B.C.D T4
CL. 1, Zone 2, GP.IIC. T4
Ta: 0...+60°C
C−TICK AS/NZS 2064 (Class A)
CE EN 61000−6−2, EN 61000−6−4 (replaces
EN 50081−2)
ATEX Zone 2 EN 60079−15:2005, EN 60079−0:2006
II 3 G EEx nA II T4
KEMA 08 ATEX 0003X
Note
The current approvals are printed on the module.
