5 Display / WBM Configuration
82
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
Note
If you click on the address of a slave in the “Slave” row of the table, you open the
“Diagnostics” page directly (Navigation: AS-i Line > Slaves > Diagnostics).
5.2.13.2 Error Statistics
Keypad/Display
AS-i Line 1 > Error List > Display... (select slave and “OK”)
Slaves on which an error has occurred are indicated by “x” in the error list.
You will find more information on the errors of the individual slaves in Section
5.2.15.1.
AS-i Line 1 > Statistics > Line statistics
AS-i power failures
Short to ground
Slave failure
Missing frame
Bad frame
Peripheral error
Protocol error
Bad master frame
Reset counters > Reset all counters
The “Line statistics” list displays all the error types and the total number of errors
on the AS-i line.
WBM: “Error Statistics” Tab
This page displays the number of errors on the AS-i line.
Note
If you click on the address of a slave in the “Slave” row of the table, you open the
page AS-i Line > Slave > Diagnostics directly.
