5 Display / WBM Configuration
63
IE/ASINTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000G8976C21603
Parameter Function
No. Consecutive number of the entry
Type Origin/source of the entry
Date/Day Date of the entry if synchronized, otherwise the time since the last restart is
displayed.
Time Time of the entry
Note
If the IE/AS-i LINK is synchronized with a time server, the current time is displayed.
Otherwise the time since the last startup is displayed.
Event Display of the diagnostic buffer entry
5.2.6.2 Events
WBM: “Events” Tab
In this tab, enable or disable the following message in the listed events:
S Message by E-mail
S Message by SNMP trap
S Entry in the diagnostic buffer
The “E-mail” and “SNMP trap” options can only be activated here if the appropriate
entries (addresses etc.) were made previously in the “Ethernet” menu, “E-mail” or
“SNMP” tabs. See Section 5.2.9.2.
