5 Display / WBM Configuration
96
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
5.2.16 Navigation “AS-i line 1 −> Change Address”
5.2.16.1 Change Address
Keypad/Display
AS-i Line 1 > Change addr. > Change slave address
The “new” address box displays only free AS-i addresses. Exit the menu with “OK”
after completing the changes.
WBM: “Change Address” Tab
On this page, you can change the addresses of the individual slaves.
Parameter Function
Old slave address Select the slave whose address you want to change.
New slave address Select the new slave address you want to assign to the slave (the free addresses
are displayed).
5.2.16.2 Change ID1
Keypad/Display
AS-i Line 1 > Change ID1 > Set ID1 (only for slave “0”)
WBM: “Change ID1” Tab
Parameter Function
Slave address Displays the slave 0(A).
ID1 can only be changed for this slave.
ID1 Configuration of the extended ID1 code of an AS-i slave (Diagnostics).
Note:
ID1 can only be changed for slave 0(A).
