5 Display / WBM Configuration
86
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
Parameter Function
Protected
mode
Select the required mode. You can choose between the following modes:
S Protected mode (option enabled)
S Configuration mode (option disabled)
Automatic address
programming
(AUP)
Enables/disables automatic address programming. If this option is selected, when
you replace a slave, the new slave is given the address of its predecessor.
Offline Enable this option to switch to offline mode (disabled = online).
In “Offline” mode, only the data record interface is active; in other words, no AS-i
frames are sent.
5.2.14.2 Total Configuration
Keypad/Display
AS-i Line 1 > Lifelist > Display... (select slave and “OK”)
Config. > Change configuration
Parameter > Change parameters
Bin. I/O > Change binary Inputs/outputs
Analog > Change analog inputs/outputs
Status
Statistics > Reset all counters
Statistics > Reset all counters
String transfer > Write (string transfer to slave)
or
AS-i Line 1 > Slave Info > Display... (select slave and “OK”)
Config. > Change configuration
...
Select a slave with the cursor buttons in the “Lifelist” or “Info” menu. Pressing “OK”
opens the “Config.” menu.
From the “Configuration” menu, use the cursor buttons “right”/“left” to change to
the other menus “Parameters”, “Bin. I/O”, “Analog” etc. With the “up”/“down” cursor
buttons, you change to the next slave. The “OK” button opens the follow-on menu
in which you can change the values. Exceptions: The “Status” and “Statistics”
menus have no display function.
Change the values with the “up”/“down” cursor keys. To transfer the changed
values to the slave, press the “OK” button.
