Siemens SIMATIC NET IE/AS-INTERFACE LINK PN IO User Manual

182
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
A AS-Interface Protocol Implementation
Conformance Statement (PICS)
PICS for IE/AS-INTERFACE LINK PN IO
Table A-1
Vendor
SIEMENS AG
Product Name IE/AS-INTERFACE LINK PN IO
Order Number 6GK1 411−2AB10 single master
6GK1 411−2AB20 double master
Version 1
Master Profile M4
Date August 2006
List of Master Functions Available
This section describes whether and how the functions can be used during
operation. Many of the functions are also available over the display or WBM.
Symbols in column 3 (M4)
Symbol Meaning
X Function exists
− Function does not exist
Table A-2
No.
Function or Call on the Host Interface
(symbolic representation)
M4 Comment / Function implemented by / see
Section
1 Image, Status = Read_IDI() X By access to the I/O data of the IE/AS-i
LINK by the PROFINET IO controller.
2 Status = Write_ODI(Image) X By access to the I/O data of the IE/AS-i
LINK by the PROFINET IO controller.
3 Status = Set_Permanent_Parameter(Addr,
Param)
X By the PROFINET parameter assignment
or by call (see Section 8.2)
4 Param, Status =
Get_Permanent_Parameter(Addr)
X see Section 8.2
5 Status, Param = Write_Parameter(Addr,
Param)
X see Section 8.2
6 Status, Param = Read_Parameter(Addr) X see Section 8.2
