Siemens SIMATIC NET IE/AS-INTERFACE LINK PN IO User Manual

5 Display / WBM Configuration
85
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
5.2.14 Navigation “AS-i Line 1 −> Configuration”
5.2.14.1 Status
Keypad/Display
AS-i line 1 > Line status > Protected > enable / disable
Autoprog. > enable / disable
Offline > “Online” / “Offline”
System error (image of the “SF” LED (line))
Configuration error (image of the “CER”
LED)
AS-i powerfail (image of the “APF” LED)
Short to ground
The functions “Protected” (protected mode or configuration mode), “Autoprog.”
(autoprogramming) or “Offline” are enabled, if the relevant check box is selected
(enable with “OK”). Exit the menu with “ESC” after enabling/disabling the functions.
WBM: “Status” Tab
