5 Display / WBM Configuration
52
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
5.1.2 Working with WBM
Buttons
S “Refresh”
If you click on this button, current data of the IE/AS-i LINK is requested and
displayed.
S ”Apply”
If you click on this button, configuration data that has been entered is stored on
the IE/AS-i LINK or downloaded to the connected slaves.
S
Printing the current view. You can make the print settings with the menu
commands “File” > “Print”, “File” > “Page Setup” or in “Tools” > “Internet
Options” > “Advanced” > “Print”.
S ”Language” list box
Select the required language for the display. The following languages are
available:
− English
− German
− French
− Spanish
− Italian
When you start WBM, the program checks the language setting of the
computer and opens the start page with the language set on the computer
assuming this language is available in WBM.
Note
Changing configuration data on the IE/AS-i LINK is only possible if you are logged
in with the “admin” login.
The “apply” button is active only if changes were made.
To move between the WBM pages, use the navigation on the left of the WBM
pages and the tabs at the top of the pages. Where possible, avoid using the
browser “backwards” and “forwards” buttons.
