8 Using the Data Record Interface
153
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
8.2.2.2 Get_Permanent_Parameter
Meaning
This call reads out slave-specific parameters stored on the IE/AS-i LINK.
The job cannot be used for all slaves of the combined transaction type.
Structure of the RecordDataRead service − Index 4
Byte Meaning
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Version_hi = 0x00
1 Version_lo = 0x00
2
0x0
Parameter
P3 P2 P1 P0
3 Reserved 0x00
