Siemens SIMATIC NET IE/AS-INTERFACE LINK PN IO User Manual

5 Display / WBM Configuration
79
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
5.2.11.4 Error
WBM: “Error” Tab − counting and evaluation of transmission errors
This page displays information on any errors that may have occurred and allows
diagnostics.
If you click on an entry, the Packet Error Statistics graphic is displayed. You then
see a configurable graphical representation of the counter value.
Parameter Function
Port LAN interface of the IE/AS-i LINK (1 or 2)
CRC Number of packets with a valid length but bad checksum
Undersize Number of packets that were too short with valid checksum
Oversize Number of packets that were too long with valid checksum
Jabbers Number of packets that were too long without valid checksum
Collisions Number of collisions that occurred
