Siemens SIMATIC NET IE/AS-INTERFACE LINK PN IO User Manual

8 Using the Data Record Interface
166
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
8.2.2.15 Read_ID−Code
Meaning
With this call, the ID code of an AS-i slave can be read out directly over the AS-i
cable. The call is intended for diagnostic purposes and is not required in the normal
master mode.
Structure of the RecordDataRead service − Index 34
Byte Meaning
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Version_hi = 0x00
1 Version_lo = 0x00
2
0x0 ID code
3 Reserved 0x00
