2 Procedure − Configuration
This chapter...
This chapter provides you with an overview of the steps and procedures involved
in configuring the IE/AS-i LINK. You will learn the basic steps leading to
commissioning and the configuration options made available to you by the IE/AS-i
LINK.
2.1 What to do − an Overview
Preparations up to Commissioning
Before putting the system into operation, the following independent steps must first
be worked through:
Write your user
program with analog
value access for the
PROFINET IO
controller
−> Section 7.3
Configure the
PROFINET IO controller
with IE/AS-i Link as
PROFINET IO device and
AS-i master
−> Chapter 6
Configure a PROFINET IO
system in HW Config of
STEP 7
Putting into operation
−> Chapter 3
Write your user
program with binary
value access for the
PROFINET IO
controller
−> Section 7.2
For example, create a program
for an S7 CPU with a PROFINET IO
interface in LAD/FBD/STL
Connecting up the
IE/AS-i Link and the slaves
incl. address assignment and,
if required, adopting the actual
as the expected configuration
−> Chapter 3
