4 Keypad and Display
40
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
Protected Mode
If the IE/AS-i LINK is in protected mode, it only exchanges data with slaves that
are “configured”. In this sense, “configured” means that the slave addresses stored
on the IE/AS-i LINK and the configuration data match the values of the existing
AS-i slaves.
You enable protected mode by downloading the configuration from the PG to the
Link module (HW Config > Download to Module...) or with the three options
mentioned in the previous section “Configuration Mode”.
4.2 Buttons and Working in the Menus
Buttons
You make your entries using cursor buttons and the “ESC” and “OK” buttons
(illustrated in Section 1.9). The buttons have the following functions:
S “right”/“left” cursor buttons , :
Navigation within the menu structure and menu lists
S “up”/“down” , :
− Navigation in the menu structure and menu lists
− Changing alphanumeric characters
S “ESC” button :
Exits the current menu (you move up one level in the menu structure)
S “OK” button :
− Opens a follow-on menu or
− Saves your input
In the description of the menu paths in Section 4.4 and 5, the “ > ” character
stands for pressing the “OK” button and, where necessary, navigating to the
required menu entry.
Meaning in the Menus
S Changing characters
You can change the value of alphanumeric characters with the “up”/“down”
buttons. Possible values are: a...z, A...Z, 0...9, −, .
Using the “right”/“left” cursor keys within a character string, you move to a
different character.
