9 Diagnostics
176
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
Remove interrupt
If a configured AS-i slave fails, a remove module interrupt is generated at the
assigned slot.
Insert interrupt
When a configured AS-i slave returns, an insert module interrupt is generated at
the assigned slot.
Insert interrupt wrong module
If the wrong AS-i slave returns (different from the configured slave), an insert
interrupt wrong module is generated at the assigned slot.
9.2.2 Diagnostic Interrupts
These interrupts instigate channel diagnostics (PROFINET IO format ID 8000
H
).
Slave-specific diagnostic interrupts (for example slave I/O error) are signaled over
the logical I/ address or the diagnostic address of the relevant slot (slot 1−63,
101−163).
Line-specific diagnostic interrupts (for example AS-i Powerfail) are signaled over
the logical I/O address or diagnostic address of the line proxy module (slot 0 or
100).
Notice
The IE/AS-i LINK only signals diagnostic interrupts when the IE/AS-i LINK is ope-
rating in protected mode and when the particular diagnostic interrupt is enabled in
the PROFINET IO configuration.
“Diagnostics entering state” interrupt
The interrupt is output when a diagnostic interrupt is generated.
“Diagnostics exiting state” interrupt
The interrupt is output when a generated diagnostic interrupt disappears.
