5 Display / WBM Configuration
80
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
5.2.12 Navigation “PROFINET IO −> Status”
This page displays information on PROFINET IO.
5.2.12.1 Status
Keypad/Display
PROFINET > Info > Device name > Change PROFINET device name
IP address Controller
Controller name (PROFINET device name of controller)
Connection (AR status online/offline)
Controller (Controller status RUN/STOP)
Update time [ms]
PROFINET > Error
WBM: “Status” Tab
Parameter Function
PNIO device name Displays the PROFINET device name of the link
Controller IP address Displays the IP address of the PROFINET IO controller
Controller name Displays the PROFINET device name of the controller
Connection status Display of the connection status (online / offline) between link and
PROFINET IO controller. See also Section 8.2.1.8.
Controller status Display of the operating state of the controller (RUN / STOP)
Update time Display of the set update time in milliseconds
